4 Zone Mixer Amplifier PMS-4150 & PMS-4300 & PMS-4420 & PMS-4550, is an practical designed commercial mixer amplifier, which built-in 150W/300W/420W/550W amplifier and 3 audio sources (USB, Bluetooth and FM Tuner). Volume and tone control for power output. 2 AUX inputs, 4 MIC 6.3 Jack (MIC1 has top priority) and 1 audio output. Treble, bass, Mic echo sound level and zone volume can be adjusted independently.
Features
l Built-in USB, FM tuner, Bluetooth and 2 external AUX inputs as audio sources;
l Strong power RMS 150W / 300W / 420W / 550W;
l Volume and tone (treble & bass) control for MP3/Tuner, AUX and MICs;
l Echo volume level for microphone adjustable;
l 4 zones sound level control independently;
l Microphone mute vox level control;
l 4-16 ohm, 70V, 100V speaker output;
l High quality copper transformer ensures best sound performance;
l Shortcircuit, over heat, over load protection
Specification
|
Model No. |
PMS-4150 |
PMS-4300 |
PMS-4420 |
PMS-4550 |
|
Power |
150W |
300W |
420W |
550W |
|
Speaker Outputs |
4-16Ω, 70V，100V |
|||
|
Input Sensitivity |
Mic: 5mV/600Ω unbalanced 6.3mm phone jack input | AUX:250mV/15KΩ RCA input |
|||
|
Tuner Frequency |
FM:87.5~108MHz | AM:530~1710KHz |
|||
|
Frequency Response |
90-16KHz |
|||
|
S/N Ratio |
Mic: 66 dB | AUX: 75 dB |
|||
|
THD |
< 1% at 1KHz, 1/3 rated power |
|||
|
Audio Source |
MP3 (USB), Tuner (FM), Bluetooth, AUX input x 2 |
|||
|
Protection |
High temperature, overload & short circuit |
|||
|
Power Supply |
220V~240V 50/60Hz or 110V |
|||
|
Material & Finish |
Aluminum front panel, metal case |
|||
|
Dimension |
485 x 330 x 88 mm |
|||
|
Weight |
9.8 kg |
12.5 kg |
16.9 kg |
19 kg |
