Model No.

PRA-S2010

PRA-S2012

PRA-S2015

Output (8Ω Stereo Power)

2x1000W

2x1200W

2x1500W

Output (4ΩStereo Power)

2x1500W

2x1800W

2x2250W

Frequency Response

 20Hz~20kHz(±0.5dB)

THD+N

<0.02%@8Ω 1kHz

S/N Rate

>100dB(A Weight)

Slew Rate

20V/µ S

Damping Factor

>200 @ 8Ω

Crosstalk

>60dB @ 8Ω 1kHz

Input Impedance

20kΩ(Balance)/ 10kΩ(Unbalance)

Input Sensitivity

0.775V/1V/1.4V

Protect

DC, Short Circuit, Over Heat and Soft-Start Protection

Front Panel CNT

Power Switch, CHA, CHB Volume

Rear Panel CNT

Mode, Sensitivity

Size

3U(48.2cm/Lx49.5cm/Dx13.2cm/H)

Packing Dimension

570mmx550mmx180mm

Weight

31.00 Kg

34.00 Kg

36.00 Kg
