2 Zone Mixer Amplifier with USB/SD/FM Tuner/Bluetooth PMS-260D PMS-212D

Small and compact design, built-in USB,SD,FM tuner, Bluetooth and 1 external AUX inputs as audio sources; Pure copper transformer drives strong power RMS 60W, 120W and 180W;4-16 ohm, 70V, 100V speaker output;2 zone with individual volume control;Mic, AUX, MP3, treble, bass, and master volume control;High quality copper transformer ensures best sound performance;Shortcircuit, over heat, over load protection;AC 220-240V power supply;Remote controller
  • Model:PMS-260D PMS-212D PMS-218D
  • Power:60W 120W 180W
  • Function:MP3, USB, SD, BLUETOOTH, 2 ZONES
Details

Features

l  Small and compact design, built-in USB,SD,FM tuner, Bluetooth and 1 external AUX inputs as audio sources;

l  Pure copper transformer drives strong power RMS 60W, 120W and 180W;

l  4-16 ohm, 70V, 100V speaker output;

l  2 zone with individual volume control;

l  Mic, AUX, MP3, treble, bass, and master volume control;

l  High quality copper transformer ensures best sound performance;

l  Shortcircuit, over heat, over load protection;

l  AC 220-240V power supply;

l  Remote controller



Specification

Model No.

PMS-260D

PMS-212D

PMS-218D

Power

60W

120W

180W

Speaker Outputs

4-16Ω, 100V

Input Sensitivity

Mic: 5mV/600Ω unbalanced 6.3mm phone jack input | AUX:350mV/10KΩ RCA input

Frequency Response

60-20KHz

S/N Ratio

Mic: 66 dB | AUX: 80 dB

THD

< 1% at 1KHz, 1/3 rated power

Audio Source

MP3 (USB/SD), Tuner, Bluetooth, RCA AUX, 6.35mm MIC input

Protection

High temperature, overload & short circuit

Power Supply

220V~240V 50/60Hz or 110V

Material & Finish

Aluminum front panel, metal case

Dimension

240 x 245 x 88 mm

Weight

4.8 kg

6.2 kg

7.9 kg
