Features
l 4 zone Cost –effective mixer power amplifier;
l 3 MIC, 3AUX inputs, 1 line output, MIC1 has priority(mute function);
l Power outputs: 4-16Ω, 70V, 100V., 4 zones outputs;
l Bass control, treble control, individual volume and master volume control;
l Chime function, siren function, telephone input function;
l Protecton(with self-lock function), DC voltage, overload, short circuit.
Specification
|
Model No. |
PMA-A4060S |
PMA-A4100S |
PMA-A4150S |
PMA-A4200S |
PMA-A4250S |
PMA-A4300S |
PMA-A4500S |
||||||
|
Rated Power |
60W |
100W |
150W |
200W |
250W |
300W |
500W |
||||||
|
Speaker Outputs |
4-16Ω, 70V, 100V |
||||||||||||
|
Line Out |
600Ω/1V(0dB) |
||||||||||||
|
Input |
Mic1,2,3/600Ω, 2.0mV(-54dB), unbalanced/AUX1,2,3/10KΩ,250mV(-10dB),unbalanced |
||||||||||||
|
Frequency Response |
100Hz-16KHz |
||||||||||||
|
THD |
< 0.1% at 1KHz |
||||||||||||
|
S/N Ratio |
Mic1,2,3: 66dB AUX1,2,3: 70dB |
||||||||||||
|
Tone Ajustment |
Bass:±10dB at 100Hz Treble: ±10dB at 10KHz |
||||||||||||
|
Protection |
Power on, overload, high temperature, DC voltage & short circuit Protection |
||||||||||||
|
Mute |
MIC1, chime function, siren function has priority |
||||||||||||
|
Voltage |
AC220/50-60Hz |
||||||||||||
|
Power Consumption |
100w |
150w |
20w |
250w |
300w |
400w |
600w |
||||||
|
Dimension |
487mmx 380mmx 90mm |
||||||||||||
|
Weight |
10.5kg |
12kg |
13kg |
13.5kg |
14kg |
15kg |
18.8kg |
||||||
