Features
l With 485 communication port, support broadcast control host;
l 485 control and DC12V trigger control port optional;
l With 1 channel short-circuit emergency input port, can turn on all the channels once the short-circuit trigger;
l With 16 channels controlled DC 24V/250W power output, no interference with each other;
l LED indicator to display the working status, easy and clear.
Specification
|
Model No. |
PAS-6215 |
|
Output Voltage |
DC 24V |
|
Output Channel |
16 Channels |
|
Output Power |
250W |
|
Communication |
9600bps |
|
STD Communication Protocol |
RS-485 |
|
STD Communication Port |
RJ45 |
|
Control Mode |
Controlled/Manual |
|
Power Input |
AC220~240V/50Hz |
|
Power Consumption |
70W |
|
Dimension |
485×357×90mm |
|
Weight |
5.5Kg |
