Features:
l Control zones, power management, audio sources and paging from remote place up to 1km distance;
l High quality of voice transaction, anti-interference, low distortion and work good from long distance;
l One audio line input from local, and volume can be controlled;
l 128x64 screen display, easy for sound management;
l Mic volume control, and devices expandable.
Specification:
Model No. |
PAS-218 |
Audio Input |
1KΩ/750mV unbalanced |
Audio Output |
1KΩ/1V balanced |
Distortion |
< 0.1% |
Frequency Response |
30~20KHz |
Control Interface |
RJ45 |
Communication Protocol |
RS-485 |
Power Consumption |
10W |
Power Supply |
12V / 50Hz |
Dimension |
236×171×72mm |
Weight |
3.5Kg |
