Integrated Features:

 Carrier Frequency Range: 600-920MHz (depends on the local technology)

 Stability: ±0.005％(﹣10℃- 50℃)

 Deviation: ±40KHz (with the function of compressing and expanding, and

  the circuit of volume auto-limited)

 S/N: ＞100dB

 Distortion: ＜0.5％@ 1KHz

 Frequency Response: 50Hz ~18KHz ±3dB

Receiver Specification:

Receiver Mode: choose signal not automatically

Modulation mode: FM

Sensitivity: when input 6dBV signal, and the deviation is 40KHz, S/N＞80dB

Harmonic Interference Ratio: ＞80dB

Gloss Interference Ratio: ＞63dB

Frequency Output: 770Mv / 5KW Impedance

Power Supply: 12V ~ 15V

Rated power consumption: 5W
